Features: Good conductivity, easy processing, fast vulcanization speed, stable resistance, long service life, good adhesion with insulation layer, can be molded or injected.
Application: Cable connector conductive core, cable accessory stress cone, outer shielding layer encapsulation, etc.
Technical sheet:
| TypicalPropertiesData | MODELNUMBER | |||
| Performance | Unit | |||
| Project | HL-3845 | HL-3350D | HL-3360D | |
| Shorehardness | Shore A | 44 ± 2 | 50±2 | 60±2 |
| Appearance | Black | Black | Black | |
| Density | g/cm3 | 1.12± 0.02 | 1.13 ± 0.02 | 1.15±0.02 |
| Tensile strength | MPa | ≥6.0 | ≥6.0 | ≥6.0 |
| Elongation | % | ≥450 | ≥300 | ≥250 |
| Permanent set | % | ≤4.5 | ≤5.5 | ≤7.5 |
| Tear strength | KN/m | ≥15 | ≥15 | ≥12 |
| Volumeresistivity | Q·cm | 10~100 | 10~100 | 10~100 |
● Physical data in the above table is for reference only.
● Sulfurization conditions: 175 ℃ for 5 minutes, with a liquid vulcanizing agent addition ratio of 0.65%, mainly composed of 2,5-dimethyl-2,5-di (tert butylperoxy) hexane.
●The supplied test report is obtained by the Quality Inspection Department with the curing conditions and testing method of the company; due to the difference of curing conditions and testing method, we can't guarantee that both parties obtain the same testing result, and we suggest that users should use the test data obtained under their own testing conditions as the reference for service performance. All the above performance data and application recommendations are only a reference for use on the service performance of product, instead of a guarantee on the effectiveness or general applicability of our products under a certain application.
