Performance: environmentally friendly and green, with both tear resistance and resilience, excellent oil resistance, high temperature resistance, corrosion resistance, and aging resistance, non-toxic and odorless;
Usage: Working in oil media in low and high temperature environments, it can produce oil seals, gaskets, and seals with good sealing performance. It is used in the pharmaceutical, chemical, and food industries, as well as in environments with high pressure requirements. Currently, it is widely used as a buffer pad between battery cells in energy storage and new energy vehicle battery modules.
Technical sheet:
| Model | Appearance | Specific gravity g/cm ³ 3 ± 0.05 | Hardness (Shore A) (±3) | Tensile Strength / MPa (≥) | Elongation at Break / % (≥) | Tear Strength / KN/m (≥) | Resilience / % (≥) | Certification |
| HL-140ZY | milky white | 1.42 | 40 | 4 | 300 | 12 | 3.3-3.6 | ROHS |
| HL-150ZY | 1.45 | 50 | 3 | 280 | 11 | 3.2-3.6 | ||
| HL-160ZY | 1.48 | 60 | 3 | 240 | 11 | 3.0-3.4 | ||
| HL-170ZY | 1.5 | 70 | 2.5 | 180 | 10 | 2.8-3.2 |
● Physical data in the above table is for reference only.
● Sulfurization conditions: 175 ℃ for 5 minutes, with a liquid vulcanizing agent addition ratio of 0.65%, mainly composed of 2,5-dimethyl-2,5-di (tert butylperoxy) hexane.
●The supplied test report is obtained by the Quality Inspection Department with the curing conditions and testing method of the company; due to the difference of curing conditions and testing method, we can't guarantee that both parties obtain the same testing result, and we suggest that users should use the test data obtained under their own testing conditions as the reference for service performance. All the above performance data and application recommendations are only a reference for use on the service performance of product, instead of a guarantee on the effectiveness or general applicability of our products under a certain application.
