Product Features:
High transparency, good processing performance, excellent physical properties
Provide products with multiple hardness levels: 40, 50, 60, 70, 80, 90
Compliant with RoHS and FDA standards
Product application:
Mainly used for high transparency LED light strips, irregular strips and other silicone products
Technical sheet:
| Model | Apparance | Hardness (Shore) | Tensilestrength (Mpa) | Elongation(0%) | Tearstrength (KN/m) | Plastity(/%o) | Density(g/cm3) |
| HL-640J | Transparent | 40 ( ± 2 ) | 6.5 | 500 | 13 | 160~180 | 1.14 |
| HL-650J | Transparent | 50 ( ± 2 ) | 7 | 400 | 15 | 190~210 | 1.17 |
| HL-660J | Transparent | 60 ( ± 2 ) | 7 | 300 | 15 | 210~230 | 1.2 |
| HL-570LED HL-571LED |
Transparent | 70 ( ± 2 ) | 6.5 | 250 | 13 | 300~320 | 1.22 |
| HL-580LED | Transparent | 80 ( ± 2 ) | 5.5 | 100 | 10 | 320~340 | 1.23 |
| HL-690J | Transparent | 90 ( ± 2 ) | 4.2 | 45 | 6 | 350~370 | 1.25 |
● Physical data in the above table is for reference only.
● Vulcanization condition: 175℃* 5Min.
● Ratio of curing agent liquid 2,5-Dimethyl-2,5-di(tert-butylperoxy) hexane: 0.65%.
●The supplied test report is obtained by the Quality Inspection Department with the curing conditions and testing method of the company; due to the difference of curing conditions and testing method, we can't guarantee that both parties obtain the same testing result, and we suggest that users should use the test data obtained under their own testing conditions as the reference for service performance. All the above performance data and application recommendations are only a reference for use on the service performance of product, instead of a guarantee on the effectiveness or general applicability of our products under a certain application.
