Product Introduction:
The general molded silicone rubber compound is the basic product for molding rubber, which is easy to open, color and process. Rebound after vulcanization Good performance, low compression permanent deformation, and good physical and mechanical properties.
Silicone rubber has excellent resistance to high and low temperatures, ozone, high temperature service life, and mechanical strength at high temperatures. The heat resistance of silicone in air It has much better properties than organic glue, and its physical properties remain basically unchanged at 150 degrees, making it suitable for semi permanent use.
Product application:
Widely used in the production of various electronic and electrical accessories, phone and computer covers, sealing gaskets, tableware and kitchenware, watch straps, wallets Lampshades, baby products.
Technical sheet:
| Pertormance | 630A | 640A | 650A | 660A | 670A | 680A | |
| Before Vulcanization | Appearance | Milky White | Milky White | Milky White | Milky White | Milky White | Milky White |
| Translucent | Translucent | Translucent | Translucent | Translucent | Translucent | ||
| Specific Gravity (25℃) (±0.03) | 1.12 | 1.14 | 1.16 | 1.18 | 1.2 | 1.22 | |
| Williams Plasticity (±20) | 150 | 170 | 190 | 240 | 280 | 300 | |
| Vulcanizing Agent | Name | C-14 | C-14 | C-14 | C-14 | C-14 | |
| Dosage (phr) | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | |
| After Vulcanization | Hardness (Shore A) (±3) | 30 | 40 | 50 | 60 | 70 | 80 |
| Tensile Strength / MPa (≥) | 6 | 7 | 7.5 | 7 | 6.5 | 6 | |
| Elongation at Break / % (≥) | 700 | 550 | 500 | 380 | 300 | 200 | |
| Tear Strength / KN/m (≥) | 15 | 16 | 17 | 16 | 15 | 12 | |
| Resilience / % (≥) | 45 | 48 | 50 | 45 | 40 | 38 | |
● Physical data in the above table is for reference only.
● Vulcanization condition: 175℃* 5Min.
● Ratio of curing agent liquid 2,5-Dimethyl-2,5-di(tert-butylperoxy) hexane: 0.65%.
●The supplied test report is obtained by the Quality Inspection Department with the curing conditions and testing method of the company; due to the difference of curing conditions and testing method, we can't guarantee that both parties obtain the same testing result, and we suggest that users should use the test data obtained under their own testing conditions as the reference for service performance. All the above performance data and application recommendations are only a reference for use on the service performance of product, instead of a guarantee on the effectiveness or general applicability of our products under a certain application.
